铂金硫化硅胶编织软管BPB20系列

东莞市格雷特硅胶制品有限公司

铂金硫化硅胶编织软管BPB20系列

 Platinum  vulcanization silicone braided hose BPB20

产品应用：

铂金硫化硅胶软BPB20系列广泛用于高低温食品乳制品和食品用油类、化妆品、化工和制药行业和生物工程用的液体或半液体流体的产品输送，（如牛奶，果汁；食品机械设备用连接管；酒类用连接导管；医药设备连接管路等,同时可配有3A，SMS，DIN，CLAMP快速接头）

产品描述：

食品级硅胶软管采用聚脂编织和铂金硅胶组合而成。广泛的应用于通过食品，医药及化妆用品，生物工程的液体和半流体。

标准长度为20米每卷，同时我们也可以根据客户的要求生产规定的尺寸和长度，胶管产品通过美国FDA级和USP Class VI和德国BFR认证。

产品特性：

铂金硫化硅胶软BPB20系列：

——工作温度范围‘-60ºC / +180ºC (-76ºF / +356ºF)在短时间内可达到  220ºC (392ºF)

——具有很好弯曲性，内壁光滑清洁，易清洗不粘水，用清洗物清洗后不附着任何残留物，可采用高温高压蒸汽消毒和灭菌。

——无嗅、无味,完全无毒，不含任何塑化剂和添加剂成分。完全符合食品FDA和生物医用级USP VI的要求。

——这些管通常是半透明的，可以观察到流体的动向。我们也可根据客户所需颜色来订制。

品质认证：

——铂金硅胶软管通过美国FDA 21 CFR 177.2600(食品和药物管理局)食品级认证。

——铂金硅胶软管通过德国BfR零件 XV标准认证和LFBG认证。

——铂金硅胶软管符合通过美国医用USP Class VI级标准认证。

——铂金硅胶管依照欧盟指令2008/95 / ECC的限制使用某些有害物质(RoHS)认可

——铂金硅胶软管符合ISO10993,NSF51和欧洲药典3.1.9的要求。

Product application:

Widely used for transportation or delivery of low temperature food, cosmetics, chemical materials or the fluid or semi liquid fluid of pharmaceutical industry and biological engineering.(such as milk, fruit juice; the connection hoses used on food machinery liquor equipment; oil production equipment and medical equipment,and can be equipped with 3A, SMS, DIN, CLAMP quick connector).

Product description:

-Silicone hose is made by the polyester braiding and platinum silicone. Widely used in the industry of liquid and semi fluid food, medicine and cosmetic products, bio engineering.

-Standard length is 20 meters per roll, and we can produce the specified size and length according to customer requirements.Our hose products pass the certification of the United States FDA grade and Class VI USP and German BFR.

Product characteristics:

-The working temperature range of -60 to +180 degree Celsius (-76 to +356 degree Fahrenheit) in a short period of time can reach 220 degrees Celsius (392 degrees Fahrenheit)

-With a good bend, the inner wall is smooth and clean, easy to be washed, no water sticking,

After cleaned by cleaning materials, no residue remained. The steam disinfection and sterilization can be done under high temperature and high pressure.

-Odorless, tasteless, non-toxic, does not contain any additives and plasticizer. Fully comply with the requirements of food FDA and biological medical grade VI USP.

-These tubes are usually translucent and the movement of fluid inside can be observed. The hose color can be customized according to customer's needs.

Quality certification:

-Platinum silicone hoses pass the United States FDA 21 CFR 177.2600 (food and Drug Administration) food grade certification.

-Platinum silicone hoses pass the German BFR parts XV standard certification and LFBG certification.

-Platinum silicone hose is in accordance with the United States Class VI USP grade standard certification.

-Platinum silicone hose is in accordance with the EU directive 2008/95/ECC limitation usage of certain hazardous substances (RoHS) recognition.

-Platinum silicone hose is in accordance with ISO10993, NSF51 and European Pharmacopoeia 3.1.9 requirements.
