高透明耐高温制药级硅胶管

所属分类：制药级硅胶软管
点击次数：0
发布日期：2019-01-09 00:00:00
在线询价

详细介绍

产品应用：

广泛应用于化学品处理，食品饮料，医疗研究，水处理工程，制药类，实验室，印刷，生物技术，半导体，生命科学（组织和细胞培养，发酵）等行业。

人体注射液，血清类输送。不含邻苯二甲酸盐塑化剂，不会渗入其它的传输液体。

产品特性：

材料：卫生级铂金硅胶料加工而成。

表面：表面精度高，没有任何味道，无色。具有非溶血性。

——无嗅、无味,完全无毒，不含任何塑化剂和添加剂成分。完全符合食品FDA和生物医用级USP VI的要求。

——这些管通常是外层为透明铂金硫化硅胶。

品质认证：

——软管通过美国FDA 21 CFR 177.2600(食品和药物管理局)食品级认证。

——软管通过德国BfR零件 XV标准认证和LFBG认证。

——软管依照欧盟指令2008/95 / ECC的限制使用某些有害物质(RoHS)认可。

品名 PART NAME	管号 HOSE NO	内径 INNER DIA		外径 OUTER DIA		工作压力 WORK PRESSURE		爆破压力 BURST PRESSURE		弯曲半径 BEND RADIUS		真空度 VACUUM		标准长度 STANDARD LENGTH
品名 PART NAME	管号 HOSE NO	mm	inch	mm	inch	bar（tested at 20 degree Celsius）	psi (tested at 68 degree Fahrenheit)	bar（tested at 20 degree Celsius）	psi (tested at 68 degree Fahrenheit)	mm	inch	Bar	Psi	米/根 METERS PER PC
BH00-0155	#15	4.76	3/16"	7.92	0.31"	0.90	13.05	2.7	39.15	20	0.79	N/A	N/A	200
BH00-016	#16	3.18	1/8"	6.34	0.25"	1.45	21.03	4.35	63.08	30	1.18	N/A	N/A	200
BH00-017	#17	6.35	0.25"	9.60	0.36"	0.90	13.05	2.7	39.15	40	1.57	N/A	N/A	200
BH00-018	#18	7.90	0.31"	11.11	0.42"	1.00	14.50	3	43.50	60	2.36	N/A	N/A	200
BH00-024	#24	6.40	0.25"	11.40	0.42"	1.00	14.50	3	43.50	90	3.54	N/A	N/A	200
BH00-025	#25	4.80	3/16"	8.00	0.31"	2.40	34.80	7.2	104.40	110	4.33	N/A	N/A	200
BH00-026	#26	6.40	0.25"	13.00	0.52"	2.70	39.15	8.1	117.45	150	5.91	N/A	N/A	100
BH00-035	#35	7.90	0.31"	14.70	0.57"	1.40	20.30	4.2	60.90	200	7.87	N/A	N/A	100
BH00-036	#36	9.50	0.37"	14.70	0.43"	2.70	39.15	8.1	117.45	280	11.02	N/A	N/A	100
BH00-070	#70	7.90	0.31"	18.90	0.57"	1.40	20.30	4.2	60.90	200	7.87	N/A	N/A	100
BH00-073	#73	7.90	0.31"	16.10	0.57"	1.40	20.30	4.2	60.90	200	7.87	N/A	N/A	100
BH00-082	#82	12.70	0.50"	19.30	0.75"	2.70	39.15	8.1	117.45	200	7.87	N/A	N/A	100
BH00-087	#87	12.70	0.50"	25.30	1.00"	2.40	34.80	7.2	104.40	200	7.87	N/A	N/A	100
BH00-088	#88	12.70	0.50"	22.20	1.00"	1.40	20.30	4.2	60.90	200	7.87	N/A	N/A	100
BH00-088	#89	15.90	0.62"	22.20	0.87"	1.40	20.30	4.2	60.90	200	7.87	N/A	N/A	100
BH00-091	#91	19.05	0.75	32.60	1.25"	2.40	34.80	7.2	104.40	350	13.78	N/A	N/A	100

Product application:

Widely used in chemical materials treatment, food and beverage, medical research, water treatment projects, pharmaceutical,

laboratory, printing, biological technology, semiconductor, Life sciences (tissue and cell culture, fermentation), etc.

also used for human injection and serum delivery. The hose does not contain adjacent benzene two formate plasticizer and

the transmission fluid will not penetrate.

Product description:

-used in liquid and semi fluid food of medicine and cosmetic products, bio engineering.

-Standard length is 20 meters per roll, and we can also to produce the specified size and length according to customer requirements.Our hose products has passed the certification of the United States FDA grade and Class VI USP and German BFR.

Product characteristics:

Material:Sanitary grade platinum silicone materials.

Surface: high accuracy on the surface,tasteless, colorless and Non hemolytic

-odorless, tasteless, non-toxic, does not contain any additives and plasticizer. Fully meet the requirements of food FDA and biological medical grade VI USP.

-the outer layer of these hoses is the transparent platinum vulcanization silicone.

Quality certification:

-pass the United States FDA 21 CFR 177.2600 (food and Drug Administration) food grade certification.

-pass the German BFR parts XV standard certification and LFBG certification.

-in accordance with the EU directive 2008/95/ECC limitation usage of certain hazardous substances (RoHS) recognition.

-in accordance with ISO10993, NSF51 and European Pharmacopoeia 3.1.9 requirements.
